Product Summary

The CA0612JRNPO9BN221 capacitor consists of a rectangular block of ceramic dielectric in which a number of interleaved metal electrodes are contained. This structure gives rise to a high capacitance per unit volume. The inner electrodes are connected to the two end terminations and finally covered with a layer of plated tin (NiSn). All part numbers are identified by the series, size, tolerance, TC material, packing style, voltage, process code, termination and capacitance value.

Parametrics

Absolute maximum ratings:(1)size – inch based (metric): 0508 (1220); (2)tolerance: J = ±5%; (3)packing style: R = paper taping reel; reel 7 inch; (4)TC material: NPO; (5)rated voltage: 50V; (6)process: X7R/Y5V.

Features

Features: (1)Supplied in tape on reel; (2)Nickel-barrier end termination; (3)0508 (4x0402) / 0612 (4x0603) capacitors (of the same capacitance value) per array; (4)Less than 50% board space of an equivalent discrete component; (5)High volumetric efficiency; (6)Increased throughout, by time saved in mounting; (7)RoHS compliant; (8)Halogen Free compliant.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CA0612JRNPO9BN221
CA0612JRNPO9BN221
Yageo
Capacitor Arrays & Networks 220pF 50V NPO 5%
Data Sheet
0-4000: $0.07
4000-20000: $0.07
20000-40000: $0.06
40000-60000: $0.06
