Product Summary

The MLK0603L1N8ST000 is a SMD inductor(coil) for high frequency(multilayer).

Parametrics

MLK0603L1N8ST000 absolute maximum ratings: (1)Inductance: 1.8nH; (2)Inductance tolerance: +-0.3nH; (3)Test frequency L(MHz): 100MHz; (4)Q min: 6; (5) Test frequency Q: 300(MHz); (6)Self-resonant frequency: 10.0(GHz); (7)DC resistance: 0.27Ω; (8)Rated current max: 300(mA).

Features

MLK0603L5N6ST000 features: (1)Inductance values are supported from 1 to 33nH; (2)With the adoption of a giga-spiral laminated structure, selfresonant frequency higher than that of the MLG structure can be obtained, while the decrease of Q in the GHz band is limited; (3)Advanced monolithic structure is formed using a multilayering and sintering process with ceramic and conductive materials for high-frequency; (4)There is no directivity; (5)The products contain no lead and also support lead-free soldering; (6)It is a product conforming to RoHS directive.

Diagrams

MLK0603L10NJ
MLK0603L10NJ
TDK
RF Inductors 0201 10nH 5%
Data Sheet
0-1: $0.11
1-10: $0.08
10-100: $0.07
100-500: $0.05
MLK0603L12NJ
MLK0603L12NJ
TDK
RF Inductors 0201 12nH 5%
Data Sheet
0-1: $0.11
1-10: $0.08
10-100: $0.07
100-500: $0.05
MLK0603L15NJ
MLK0603L15NJ
TDK
RF Inductors 0201 15nH 5%
Data Sheet
0-1: $0.11
1-10: $0.08
10-100: $0.07
100-500: $0.05
MLK0603L18NJ
MLK0603L18NJ
TDK
RF Inductors 0201 18nH 5%
Data Sheet
0-1: $0.11
1-10: $0.08
10-100: $0.07
100-500: $0.05
MLK0603L1N0S
MLK0603L1N0S
TDK
RF Inductors 0201 1.0nH 0.3nH Tol
Data Sheet
0-1: $0.11
1-10: $0.08
10-100: $0.07
100-500: $0.05
MLK0603L1N1S
MLK0603L1N1S
TDK
RF Inductors 1.1nH
Data Sheet
0-1: $0.03
1-50: $0.02
50-100: $0.02
100-500: $0.02
