Product Summary
The BLM18HG601SN is a on-board type(DC) EMI suppression filter. It generates a high impedance which at high frequencies mainly consists of a resistance element. The BLM18HG601SN is effective in circuits without stable groud lines because the device does not need a connection to ground.
Parametrics
BLM18HG601SN specifications: (1)Quantity (pcs.): 20; (2)Impedance typ.(at 100MHz, 20 degree C): 600Ω±25%(typ); (3)Rated Current (mA): 200; (4)DC Resistance (W) max.: 1.00.
Features
BLM18HG601SN features: (1)It can be used in digital interface; (2)Resistance of it especially grows in the lower frequency range. Therefore it is less effective for digital signal waveform at low frequency range and can suppress the ringing; (3)It generates an impedance from the relatively low frequencies. Therefore it is effective in noise suppression in the wide frequency range(30MHz-several hundred MHz).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BLM18HG601SN1B |
Murata |
EMI Filter Beads, Chokes & Arrays 0603 600ohm |
Data Sheet |
Negotiable |
|
||||||||||||
 |
BLM18HG601SN1D |
Murata |
EMI Filter Beads, Chokes & Arrays 0603 600 OHM |
Data Sheet |
|
|
||||||||||||
