NCP3063DR2G

monolithic DC-DC converter, 1.5 A, sop8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.55~0.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.55~0.65

PartNumber:: NCP3063DR2G

Brand:: ON SEMICONDUCTOR - ONS | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ke's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-30

From Other Seller

Part Number:NCP3063DR2G
US $0.55 - 0.65
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The NCP3063DR2G belongs to NCP3063 Series, which is a higher frequency upgrade to the popular MC34063A and MC33063A monolithic DC-DC converters. This series was specifically designed to be incorporated in Step-Down, Step-Up and Voltage-Inverting applications with a minimum number of external components. The NCP3063DR2G consists of an internal temperature compensated reference, comparator, a controlled duty cycle oscillator with an active current limit circuit, a driver and a high current output switch.

Parametrics

Maximum ratings: (1)VCC pin 6, VCC: 0 to +40 V; (2)Comparator Inverting Input pin 5, VCII: - 0.2 to + VCC V; (3)Darlington Switch Collector pin 1, VSWC: 0 to +40 V; (4)Darlington Switch Emitter pin 2 (transistor OFF), VSWE: - 0.6 to + VCC V; (5)Darlington Switch Collector to Emitter pin 1-2, VSWCE: 0 to +40 V; (6)Darlington Switch Current, ISW: 1.5 A; (7)Ipk Sense pin 7, VIPK: - 0.2 to VCC + 0.2 V.

Features

Features: (1)Operation to 40 V Input; (2)Low Standby Current; (3)Output Switch Current to 1.5 A; (4)Output Voltage Adjustable; (5)Frequency Operation of 150 kHz; (6)Precision 1.5% Reference; (7)New Features: Internal Thermal Shutdown with Hysteresis New Features: Cycle-by-Cycle Current Limiting; (8)Pb-Free Packages are Available.
